Omcan SPV50 Avancini 66.5 qt spiral dough mixer with 10 speeds

Product Description

The Omcan SPV50 is an Avancini spiral dough mixer with 10 speeds and a 66.5 qt bowl. It is rated 5.5 HP (4100 W) on 240 V/60 Hz/1 Ph power.

66.5 Qt Bowl Capacity

The Omcan page lists a bowl capacity of 66.5 qt (63 L) and bowl dimensions of 19.7 inch x 12.6 inch (500 x 320 mm). Bowl RPM is listed as 7 on 1st speed and 24 on 2nd speed.

Flour and Dough Capacities

The listed maximum dry flour capacity is 73.3 lb (33.3 kg) and the maximum dough capacity is 110 lb (50 kg). Spiral RPM is listed as 69 on 1st speed and 249 on 2nd speed.

5.5 HP at 24 A on 240 V

The motor is listed at 5.5 HP (4100 W) and 24 A on 240 V/60 Hz/1 Ph. The plug is listed as NEMA 6-30 P.

Specifications

Model SPV50
Omcan Item Number 49182
Bowl Capacity 66.5 qt / 63 L
Max Dry Flour Capacity 73.3 lb / 33.3 kg
Max Dough Capacity 110 lb / 50 kg
Bowl RPM 1st Speed 7, 2nd Speed 24
Spiral RPM 1st Speed 69, 2nd Speed 249
Power 5.5 HP / 4100 W
Amps 24 A
Electrical 240 V/60 Hz/1 Ph
Plug NEMA 6-30 P
Bowl Dimensions (Dia. x H) 19.7 inch x 12.6 inch / 500 x 320 mm
Net Dimensions 20.8 inch x 37 inch x 41.3 inch / 530 x 940 x 1050 mm
Net Weight 408 lb / 185 kg
Shipping Dimensions 26 inch x 43 inch x 52 inch
Shipping Weight 474 lb
Certifications cETLus Certified, ETL Sanitation Certified
Country of Origin Italy
UPC 690207491826

Warranty

Omcan lists a 1 Year Parts Warranty and a 1 Year Labor Warranty.
