Product Description

The Ice-O-Matic MFI0800R is a self-contained flake ice machine producing 900-1000 lb of ice per 24 hours on a 115V/60Hz/1-phase circuit, with heat rejection sent to a remote condenser.

Highest Output in the 21 Inch MFI0800 Family

The MFI0800R produces up to 200 lb more ice per day than the air- and water-cooled MFI0800A90 and MFI0800W90 despite sharing the same 21 x 24 x 27 inch cabinet, because remote condensing removes the local heat-rejection constraint that limits the self-contained versions. It runs on R404A refrigerant rather than the R290A used in the air- and water-cooled MFI0800 models.

Paired With the RC100G40 Remote Condenser

Ice-O-Matic pairs the MFI0800R with the RC100G40 remote condenser, sold separately, along with an RL404 lineset sized to the run length between the head and the condenser location. Sending heat rejection outdoors or to a mechanical room keeps kitchen ambient temperature lower than a self-contained air-cooled unit would.

Larger IFQ1-XL Filter for the Higher Output

Ice-O-Matic pairs the MFI0800R with the IFQ1-XL filter system, sized for the higher water throughput this model's 900-1000 lb output demands, the same filter used on the air-cooled MFI0800A90.

Specifications

Model MFI0800R
Ice Type Flake Ice
Capacity 900-1000 lb/24hr
Exterior Dimensions 21 x 24 x 27 Inch (W x D x H)
Electrical 115V/60Hz/1-Phase
Refrigerant R404A
Condenser Remote (pairs with RC100G40)
Filter System IFQ1-XL

Warranty

Ice-O-Matic publishes 3 years parts and labor on the MFI series, with 5 years parts coverage on the compressor.
