Product Description

The Ice-O-Matic ICE1506HR49 is a self-contained half cube ice machine producing 1200-1300 lb of ice per 24 hours on a 208-230V/60Hz/1-phase circuit, with heat rejection sent to a remote condenser.

A Slimline Cube Machine, Not a CIM or MFI

The ICE1506HR49 belongs to Ice-O-Matic's ICE1506 slimline series rather than the Elevation Series CIM cube line or the MFI flake line, producing half cube ice in a shallower 30.4 x 26.3 x 22.03 inch (W x D x H) cabinet sized to fit under a low counter or in a tight equipment stand. It runs on R449A refrigerant.

Paired With the RC306C49 Remote Condenser

Ice-O-Matic pairs the ICE1506HR49 with the RC306C49 remote condenser, sold separately, along with an RL49 lineset sized to the run length between the head and the condenser location. The RC306C49 also serves several CIM and GEM/MFI heads, so dealers stocking that condenser can cover this model with the same part.

Air-Cooled Sibling Available as the ICE1506HT49

Where a remote condenser location is not practical, Ice-O-Matic builds the same slimline cabinet as the air-cooled ICE1506HT49, at a slightly higher rated capacity than this remote-cooled version.

Specifications

Model ICE1506HR49
Ice Type Half Cube
Capacity 1200-1300 lb/24hr
Exterior Dimensions 30.4 x 26.3 x 22.03 Inch (W x D x H)
Electrical 208-230V/60Hz/1-Phase
Refrigerant R449A
Condenser Remote (pairs with RC306C49)
Filter System IFQ2
Shipping Weight 263 lb

Warranty

Ice-O-Matic covers ICE series cube ice machines under the same terms as the CIM series: 3 years parts and labor, with 5 years parts on evaporators and compressors.
