Product Description

The Ice-O-Matic GEM0956R49 is a 21 inch remote-cooled modular Pearl ice machine head that produces 900 to 1,000 lb of soft, chewable nugget-style ice per 24 hours, pairing with the RC106G49 remote condenser.

Remote Condensing at the Mid-Tier Output

The GEM0956R49 pairs with the RC106G49 outdoor remote condenser, a larger unit than the RC100G49 used on the smaller GEM0650R49, matched to the extra heat load of this 900-1,000 lb tier. Moving condensing outdoors keeps compressor heat and noise out of the kitchen.

Matching Output to the Air- and Water-Cooled 0956 Variants

The GEM0956R49 shares its 900-1,000 lb output and 21 in W x 24 in D x 27 in H cabinet with the air-cooled GEM0956A90 and water-cooled GEM0956W90. The 208-230V/60Hz/1-phase electrical requirement is the same across all three; only the heat-rejection path and refrigerant differ.

R449A and IFQ1-XL Filtration

The GEM0956R49 runs on R449A for the line-set run to its remote condenser, versus the R290A used in the air- and water-cooled 0956 models. It carries the same IFQ1-XL filter sizing as its 0956 siblings, one step up from the IFQ1 used on the smaller GEM0450 tier.

Specifications

Model GEM0956R49
Ice Type Pearl Ice (soft, chewable nugget-style)
Capacity 900-1000 lb/24hr
Exterior Dimensions 21 in W x 24 in D x 27 in H
Electrical 208-230V/60Hz/1-phase
Refrigerant R449A
Condenser Remote (pairs with RC106G49)
Filter System IFQ1-XL

Warranty

Ice-O-Matic publishes 3 years parts and labor on the GEM series, with 5 years parts coverage on the compressor.
