Product Description

The Ice-O-Matic CIMU300FA90 is a 30 inch self-contained undercounter cube ice maker that produces full cube ice at 300 to 400 pounds per 24 hours, air cooled, and built as a complete unit rather than a modular head requiring a separate bin.

Wider Cabinet Steps Up Output Over the CIMU220

At 30 inches wide, the CIMU300FA90 is 6 inches wider than the CIMU220FA90 and rated 300 to 400 pounds per day versus 200 to 300 pounds for the narrower unit. Both share the same 115/60/1 power, R290A refrigerant, and IFQ1-S filter system, so the CIMU300FA90 is the choice when a station needs more daily volume but can accommodate the wider footprint.

Front-Breathing Design for Tight Installations

The front-breathing design routes both air intake and condenser exhaust through the front of the cabinet, which the manufacturer states allows installation in tight or enclosed spaces where side or rear clearance is limited. This is paired with a stainless steel exterior described as corrosion-resistant and fingerprint-resistant.

Full Cube Output Matches Its Half Cube Sibling

At 300 to 400 pounds per day, the CIMU300FA90 produces the same daily volume as the half cube CIMU300HA90 in the identical 30 inch wide cabinet. Both run on the same electrical service, refrigerant, and filter system, so the choice between them comes down to ice shape rather than capacity.

Specifications

Model CIMU300FA90
Type Self-contained undercounter cube ice maker
Ice Type Full Cube
Capacity 300 to 400 lb / 24hr
Width 30 inches
Electrical 115V / 60Hz / 1-Phase
Refrigerant R290A
Condenser Air Cooled
Filter System IFQ1-S
Shipping Weight 192 lb

Warranty

Ice-O-Matic publishes 3 years parts and labor on the CIM series, with 5 years parts coverage on the evaporator and compressor.
