Product Description

The Ice-O-Matic CIM0530FR49 is a 30 1/4 inch modular ice machine head from the Elevation Series, producing 500 to 600 lb of full cube ice per 24 hours, remote cooled.

Full Cube Ice on the 30-Inch Elevation Cabinet

The CIM0530FR49 shares its 30 1/4 by 24 1/4 by 21 1/4 inch cabinet with the CIM0430 series while producing a higher 500 to 600 lb range of full cube ice per day, versus 400 to 500 lb for the CIM0430FA90. It is the full-output step up within the same footprint.

Remote Condenser Instead of a Head-Mounted Unit

Unlike the CIM0530FA90 and CIM0530FW90, which reject heat through a condenser built into the head, the CIM0530FR49 is designed for a separate remote condenser. Ice-O-Matic's own product page states this model pairs with the RC100C49 remote condenser and precharged linesets, sold in RL49-25, RL49-40, or RL49-75 lengths, letting the compressor be relocated away from the kitchen floor.

R449A Refrigerant and IFQ1-XL Filtration

The CIM0530FR49 runs on R449A refrigerant, unlike the R290A used in the air- and water-cooled CIM0530 variants, and ships with Ice-O-Matic's IFQ1-XL filter system. It is BABA compliant per the manufacturer's published specifications.

Specifications

Model CIM0530FR49
Series Elevation
Type Full Cube, modular head, bin sold separately
Capacity 500-600 lb per 24 hours
Exterior Dimensions 30.25 in W x 24.25 in D x 21.25 in H
Electrical 115/60/1
Refrigerant R449A
Condenser Remote (pairs with RC100C49 remote condenser, sold separately)
Filter System IFQ1-XL
Certifications BABA Compliant
Shipping Weight 173 lb

Warranty

Ice-O-Matic publishes 3 years parts and labor on the CIM series, with 5 years parts coverage on the evaporator and compressor. The RC100C49 remote condenser is sold separately and carries its own warranty terms.
