Product Description

The Ice-O-Matic CIM0330FA90 is a 30 1/4 inch Elevation Series ice machine head producing 300 to 400 lb of full cube ice per 24 hours, air cooled.

30-Inch Footprint for the Same 300-400 lb Output

The CIM0330FA90 produces the same 300-400 lb daily band as the narrower 22 inch CIM0320FA90, on a wider 30.25 inch chassis. Operators with the floor space to spare gain a bit more service clearance and a wider door opening for the same daily ice.

R290A Refrigerant, Air Cooled

This head runs on R290A, a low-GWP hydrocarbon refrigerant, and rejects heat locally through an air-cooled condenser. It carries Ice-O-Matic's ENERGY STAR certification, which the water-cooled CIM0330FW90 variant of this same chassis does not.

IFQ1 Filter Compatibility

Ice-O-Matic specifies the IFQ1 water filter system for this head. Running the specified filter is part of what keeps the published warranty terms in force, since scale buildup from unfiltered water is excluded from standard coverage.

Specifications

Model CIM0330FA90
Series Elevation
Type Full Cube, modular head (bin sold separately)
Capacity 300-400 lb/24hr
Exterior Dimensions 30.25 x 24.25 x 21.25 Inch (W x D x H)
Electrical 115V/60Hz/1-Phase
Refrigerant R290A
Condenser Air Cooled
Filter System IFQ1
Certifications ENERGY STAR
Shipping Weight 142 lb

Warranty

Ice-O-Matic publishes 3 years parts and labor on the CIM series, with 5 years parts coverage on the evaporator and compressor.
