Product Description

The Hoshizaki ULR93B is the largest cabinet in the Steelheart® side-mount undercounter line: 93 inches wide, three sections, three stainless steel doors, and 30.17 cubic feet of refrigerated storage under a standard counter height.

Three Sections Under One Counter

At this width the ULR93B replaces what would otherwise be two separate undercounter units with a gap between them. That gains a kitchen continuous counter above, one power cord instead of two, and one refrigeration system to maintain. Three doors keep each opening small, so a station working out of one section does not warm the other two.

Side-Mount Refrigeration on a Single 5-Amp Circuit

Despite covering nearly eight feet of line, the ULR93B draws just 5 amps at 115 volts and plugs into a standard NEMA 5-15P receptacle. The side-mounted condensing unit keeps the coil clear of floor-level grease and dust. Daily energy consumption is 1.87 kWh, and the unit is ENERGY STAR qualified — a useful number to have on hand for utility rebate paperwork on a cabinet this size.

Specifications

Model ULR93B
Type Side mount refrigerator, three section undercounter, stainless doors
Capacity 30.17 cu. ft.
Exterior Dimensions 93" W x 33.25" D x 33.875" H
Shipping Weight 455 lbs.
Crate Dimensions 95.25" L x 34.5" D x 36" H
Electrical 115V / 60 Hz / 1 phase, 5 amps
Plug NEMA 5-15P, 10 ft. cord
Refrigerant R290
Energy Consumption 1.87 kWh/day
Certifications ENERGY STAR Qualified, ETL Safety Listed (US & C), ETL Sanitation Listed, Georgia Made Certified

Warranty

7 years labor, 7 years parts, 7 years compressor.
