Product Description

The Hoshizaki SR60B-18M is a 60-inch, two-section mega-top prep table from the Steelheart Series, carrying eighteen 1/6-size pans over a 14.8 cubic foot refrigerated cabinet. It sits in the middle of the 60-inch mega-top range, above the twelve-pan model and below the twenty-four, and is the usual choice when a station needs a genuinely wide rail but not the maximum.

Eighteen Pans on a 34-Inch Cabinet

Mega-top models run 34 inches deep rather than the 30 inches of the sandwich-top line. The extra depth is what makes an eighteen-pan rail workable: there is still landing room in front of the pans instead of the operator reaching across a crowded top. Cabinet storage stays at 14.8 cubic feet net, so the added depth buys rail width, not shelf space.

Built to Hold at 100°F Ambient

This cabinet is engineered to maintain food-safe product temperatures in ambient conditions up to 100°F. Airflow is front-breathing, drawing and discharging at the front of the unit, which allows a flush installation between adjacent equipment with no side or rear clearance.

Natural Refrigerant

Cooling is by R290, a hydrocarbon refrigerant with very low global warming potential that is not subject to HFC phase-down. The unit is listed at 4.05 kWh per day and draws 4 amps from a standard 115V supply through a NEMA 5-15P plug.

Specifications

Model SR60B-18M
Configuration Two section, mega top prep table, stainless doors
Pan Capacity 18 pans, 1/6 size, 4" deep
Net Capacity 14.8 cu ft
Nominal Capacity 17.55 cu ft
Exterior Dimensions 60" W x 34" D x 44.25" H
Shipping Weight 368 lbs
Crate Dimensions 61.75" L x 36" D x 46.5" H
Cutting Board 60" x 10" x 1/2" polyethylene
Shelving One epoxy coated adjustable shelf per section
Electrical 115V / 60 Hz / 1 phase
Amperage 4 amps
Plug NEMA 5-15P, 10 ft cord
Energy Consumption 4.05 kWh/day
Refrigerant R290
Compressor 1/3 HP, 2431 BTU/hr nominal
Certifications ETL Safety Listed (US & C), ETL Sanitation, Georgia Made Certified

Warranty

Hoshizaki covers the SR60B-18M under its 7-7-7 warranty: seven years labor, seven years parts, and seven years on the compressor.
