Product Description

The Hoshizaki SR48B-18M is the high-pan-count member of the 48-inch Steelheart Mega Top family: eighteen sixth-size pans on the rail, six more than the SR48B-12M in an identical cabinet. When a station's problem is topping variety rather than storage volume, this is the unit that solves it without adding a foot of line length.

Eighteen Pans in 48 Inches

Eighteen positions is the densest rail Hoshizaki offers at this width, and it is the specification that separates this model from the otherwise identical SR48B-12M — same 48-by-34-inch footprint, same 12 cubic feet of net storage, same electrical requirement. The only thing that changes is the number of inserts the rail will hold. Pizza make-lines and build-your-own concepts are the usual buyers; a station running six or eight toppings does not need it.

Cabinet Below

Two stainless steel doors open onto separate compartments totalling 12 cubic feet net, 13.66 cubic feet nominal. Hoshizaki supplies eighteen polycarbonate pans at 4 inches deep; the rail also accepts 6-inch pans where a single high-volume item needs more capacity than a shallow insert allows.

Efficiency and Warranty

The R290 natural-refrigerant system meters 2.83 kWh per day at 3 amps on a standard 115V circuit — the same consumption as the twelve-pan version, since the refrigeration load is set by the cabinet rather than the rail. The unit carries ETL Safety and Sanitation listings for the US and Canada, is Georgia Made Certified, and comes with Hoshizaki's 7-7-7 warranty. It supersedes the discontinued SR48A-18M.

Specifications

Model SR48B-18M
Type Two section Mega Top prep table refrigerator
Series Steelheart
Net Capacity 12 cu ft
Nominal Capacity 13.66 cu ft
Doors 2 stainless steel doors
Pan Capacity 18 polycarbonate 1/6 size pans, 4" deep (accepts 6" deep)
Exterior Dimensions 48" W x 34" D x 44.25" H
Electrical 115V / 60 Hz / 1 phase, 3 amps
Plug NEMA 5-15P, 10 ft cord
Refrigerant R290
Energy Consumption 2.83 kWh/day
Certifications ETL Safety Listed (US & C), ETL Sanitation, Georgia Made Certified
Shipping Weight 315 lbs
Crate Dimensions 52.5" L x 36" D x 46.5" H

Warranty

Hoshizaki covers the SR48B-18M with its 7-7-7 warranty: seven years labor, seven years parts, and seven years on the compressor.
