Hoshizaki HC1A-HGE-HGE pass-thru Steelheart heated holding cabinet with half glass doors, right side view

Product Description

The Hoshizaki HC1A-HGE-HGE is a single-section pass-thru heated holding cabinet with half glass doors on both faces. It holds 23.82 cubic feet — twelve sheet pans or twenty to twenty-four tray slides — at a setpoint between 140 and 180°F, with dual-sided access between production and service.

Four Half Doors, Minimal Exposure

This is the most heat-conservative arrangement Hoshizaki offers in a pass-thru. Four half glass panels mean any one opening exposes a quarter of the cabinet face rather than half or all of it, and the glass lets staff confirm what is inside before opening anything at all. In a cabinet worked from both sides through a long service, that combination is what keeps the interior at setpoint instead of recovering from it.

Pass-Thru Workflow

Loaded from the kitchen and drawn from the service side, the cabinet becomes the handoff point rather than a shared cupboard both crews reach into. At 35.75 inches deep it is 2.25 inches deeper than the equivalent reach-in, which is what the second set of doors requires.

ENERGY STAR Efficiency

Rated at 161.4 kWh per day, the cabinet is ENERGY STAR qualified and UL Energy Verified. Digital controls set the hold point directly, and the unit runs from a standard 115V outlet at 10 amps through a NEMA 5-15P plug. Construction is stainless steel and the unit is Georgia Made Certified.

Specifications

Model HC1A-HGE-HGE
Configuration One section, pass-thru, half glass doors with lock
Capacity 23.82 cu ft, (12) sheet pans or 20–24 tray slides
Exterior dimensions 27.5" W x 35.75" D x 79.5" H
Shipping weight 367 lbs
Temperature setpoint range 140–180°F
Ambient operating range 45–100°F
Electrical 115V/60/1, 10 amps
Plug NEMA 5-15P
Energy consumption 161.4 kWh/day
Construction Stainless steel
Certifications ENERGY STAR Qualified, ETL Safety Listed (US & Canada), ETL Sanitation, UL Energy Verified, Georgia Made Certified

Warranty

The HC1A-HGE-HGE carries Hoshizaki's 7-7-7 warranty: seven years labor, seven years parts, and seven years on the compressor.
