Hoshizaki HC1A-FGE single section Steelheart heated holding cabinet with full glass door, right side view

Product Description

The Hoshizaki HC1A-FGE is a single-section heated holding cabinet with one full glass door, built in stainless steel on the Steelheart platform. It holds 22.7 cubic feet at a setpoint between 140 and 180°F, taking twelve sheet pans or twenty to twenty-four tray slides depending on how the interior is racked.

Glass Door for Visible Holding

The full glass door is the reason to specify this model over the solid-door HC1A-FS. Staff can read the load without opening the cabinet, which both saves the heat lost on a speculative door swing and makes the unit usable in a position guests can see — a carvery, a catering line, or a grab-and-go hot station. The door is self-closing and locks.

Tray Slides or Sheet Pans

Interior racking accepts twenty to twenty-four tray slides or twelve full sheet pans. The tray-slide count matters for banquet and healthcare operations plating to individual trays, where the constraint is slide pitch rather than pan area.

ENERGY STAR and Digital Control

The cabinet is ENERGY STAR qualified and UL Energy Verified, with digital temperature control setting the hold point directly. It runs on a standard 115V circuit at 10 amps through a 5-15P plug, needs a 15 A maximum breaker, and operates in ambient conditions from 45 to 100°F. Hoshizaki rates energy consumption at 175.5 kWh per day.

Specifications

Model HC1A-FGE
Configuration One section, reach-in, full glass door with lock
Capacity 22.7 cu ft, (12) sheet pans or 20–24 tray slides
Exterior dimensions 27.5" W x 33.5" D x 79.5" H
Shipping weight 340 lbs
Temperature setpoint range 140–180°F
Ambient operating range 45–100°F
Electrical 115V/60/1, 10 amps
Max fuse / HACR breaker 15 A
Plug NEMA 5-15P
Energy consumption 175.5 kWh/day
Construction Stainless steel
Certifications ENERGY STAR Qualified, ETL Safety Listed (US & Canada), ETL Sanitation, UL Energy Verified, Georgia Made Certified

Warranty

The HC1A-FGE carries Hoshizaki's 7-7-7 warranty: seven years labor, seven years parts, and seven years on the compressor.
