Hoshizaki F-2001MRJZ-C 30 inch remote-cooled modular cubelet ice machine

Product Description

The F-2001MRJZ-C is Hoshizaki's largest remote-cooled cubelet machine on the 30 inch modular chassis, producing up to 1,832 lbs of nugget-style ice per 24 hours. It replaces the F-2001MRJ-C and connects to a URC-series remote condensing unit.

Cubelet at Institutional Scale

1,832 lbs a day is enough for a hospital floor plan, a stadium concourse or a campus dining hall running multiple dispensers. Nugget ice is what those environments specify: it is soft enough to chew, packs a cup completely, and chills a drink faster than a cube of equivalent mass because of the surface area.

Remote Condenser, Single Phase

The condensing unit sits outside, so no heat and no compressor noise reach the space. The head runs on 208-230v single phase at 19.9 amps and takes a 30A max fuse — worth noting against the three-phase F-2001MRJZ3 flaker on the same body, which needs a three-phase supply.

Advanced CleanCycle24 and Greaseless Auger

The machine cleans itself on a 24 hour cycle and the auger runs greaseless bearings. At this duty the evaporator is working essentially without pause, and automatic cleaning is what holds rated output between scheduled service.

Specifications

Model F-2001MRJZ-C
Ice type Cubelet (nugget style)
Ice production Up to 1832 lbs. per 24 hours
Condenser Remote air-cooled
Configuration Modular, bin sold separately
Exterior dimensions 30" W x 27-1/2" D x 34-7/16" H
Shipping weight 360 lbs.
Electrical 208-230v / 60 / 1, 4-wire, 19.9 amps, 30A max fuse
Connection Hardwired at site, no plug included
Refrigerant R-404A, 8 lbs. 2.5 oz. (3700 g)
Energy consumption 4.35 kWh per 100 lbs. at 90/70
Water consumption 12 gal. potable water per 100 lbs. at 90/70
Certifications AHRI Standard 810, NSF, UL Listed, Georgia Made

Warranty

Three years parts and labor on the entire machine. Five years parts on the compressor and air-cooled condenser coil.
