Product Description

The Hoshizaki DBW-200H is a 30 inch hotel ice and water dispenser with a 200 lb built-in storage bin, push-button ice dispensing and a separate water lever. It is the model for floors where a 130 lb reservoir runs dry before housekeeping gets to it.

Capacity against dispensing rate

The DBW-200H dispenses at 13 lb per minute against the narrower DBW-130H's 20, but stores 200 lb rather than 130. On a busy floor the reservoir is what matters. A dispenser that empties at 8pm is a guest complaint regardless of how fast it was pouring before it ran out, and the larger bin buys the machine above it time to catch up.

Ice and water in one alcove

The water lever runs independently of the ice button, so a guest filling a bottle does not hold up someone filling a bucket. Ice stays enclosed behind a sealed liner and is delivered into the container rather than scooped from an open bin, which is the difference between a hygienic guest floor and a shared reservoir anyone can reach into.

Installation

A dispenser, not an ice machine: it needs a compatible ice machine mounted above. It is hardwired rather than cord-connected at 1.4 amps on 115V, and the dispensing area is ADA compliant.

Specifications

Model DBW-200H
Ice storage capacity 200 lb (5.72 cu ft)
Dispensing rate 13 lb per minute
Dispenses Ice (push button) and water (lever)
Exterior dimensions 30" W x 30" D x 53" H
Electrical 115V/60/1, 1.4 amps, hardwired (no cord or plug)
Shipping weight 220 lb
Certifications ADA Compliant, ETL Sanitation Listed, UL Safety Listed, Georgia Made Certified

Warranty

Three years parts and labor on the entire machine.
