Product Description

The Dukers DDM72R is the widest straight glass cake showcase in this Dukers line, built for production bakeries, supermarket pastry departments and hotel banquet counters that merchandise a full assortment from one position. It carries product on three shelves in a 72" wide cabinet at 33°F to 41°F.

Six feet of frontage on one compressor

Three shelves at six feet each give roughly eighteen linear feet of display surface running off a single refrigeration system and a single power circuit. Two 36" cases covering the same frontage mean two compressors to maintain, two condensers to clean and two temperature logs to keep. Depth and height stay at 28-1/2" and 51", the same as every straight glass model in the line, so the case drops into an existing counter run without a millwork change.

A larger compressor for the larger cabinet

This model steps up to a 4/7 HP compressor rather than carrying over the 4/9 HP unit used in the 36" through 60" cases. That extra capacity is what keeps a six-foot cabinet holding 33°F to 41°F consistently end to end when the case is fully loaded and being opened constantly through a morning rush, instead of running long and drifting warm at the far end from the evaporator.

Construction, lighting and controls

Stainless steel interior and exterior in a black finish, with a copper evaporator coil — copper transfers heat better than aluminum and tolerates the humidity cycling a display case sees during service. Switched interior and canopy LED lighting can be shut off at close without cycling the refrigeration, a digital readout gives staff the actual cabinet temperature for the log, and defrost runs automatically. The system uses R290 natural refrigerant on a standard NEMA 5-15P outlet.

Specifications

Model DDM72R
Type Refrigerated bakery display case, straight glass with side glass
Exterior dimensions (W x D x H) 72" x 28-1/2" x 51"
Crate dimensions (W x D x H) 74-3/4" x 33-1/2" x 56-1/4"
Net weight 661 lbs
Gross weight 728 lbs
Temperature range 33°F to 41°F
Compressor 4/7 HP
Electrical NEMA 5-15P plug
Refrigerant R290 natural refrigerant
Evaporator Copper
Defrost Automatic
Shelves 3
Lighting Interior and canopy LED with switch
Display Digital temperature readout
Construction Stainless steel interior and exterior, black finish
Warranty 2-year parts and labor, 5-year compressor

Warranty

Dukers covers this merchandiser with a 2-year parts and labor warranty and a 5-year compressor warranty from the date of purchase.
